Scott – Spark 940 2021

 3,272

The SCOTT Spark 940 has a super light carbon/alloy frame. It features a custom FOX Nude Shock, SRAM Eagle 12-speed drivetrain and our TwinLoc Suspension System to always optimize your ride.

Please note that bike specifications are subject to change without prior notice

Clear
SKU: N/A Categories: ,
This item cannot be purchased online. Please contact us.

Description

  • FRAME
    Spark 3 Carbon / IMP Technology / HMF Main Frame
    BB92 / Alloy SL 6011 swingarm
    SW dropouts for Boost 12x148mm
    “2.6” tire compatible / TBC Trunnion box construction
  • TRAVEL

    Front: 130mm / Rear 120mm

  • FORK
    RockShox Revelation RL3 Air
    custom Charger 3-Modes Damper
    15x110mm Maxle Lite / 42mm offset / Tapered steerer
    Lockout / Reb. Adj. / 130mm travel
  • REAR SHOCK
    FOX Float EVOL Performace Trunnion
    3 modes / Lockout-Trail-Descend
    DPS / Reb. Adj.
    Travel 120mm / 165X45mm
  • REMOTE SYSTEM
    SCOTT TwinLoc TSP
    Suspension-Seatpost Remote
    below Bar / 3 modes / integ. Grip clamp
  • REAR DERAILLEUR
    SRAM NX / Eagle 12 Speed
  • SHIFTERS

    SRAM SX Eagle Trigger

  • CRANKSET
    SRAM X1 Eagle DUB Boost
    32T
  • BB-SET

    SRAM DUB PF integrated / shell 41x92mm

  • CHAIN

    SRAM CN NX Eagle

  • CASSETTE

    SRAM SX-PG1210 / 11-50 T

  • BRAKES

    Shimano MT501 Disc

  • ROTOR

    Shimano SM-RT54 CL / Av. et Ar. 180 mm

  • HANDLEBAR
    Syncros Fraser 2.0 / Alloy 6061
    T shape Flat / 9° / 760mm
    Syncros Pro lock-on grips
  • STEM
    Syncros FL2.0 / 6061 Alloy
    6° / integrated Top Cap / 31.8mm / 1 1/8″
  • SEATPOST
    Syncros Duncan Dropper Post 2.5
    31.6mm / S size 100mm / M, L & XL 125mm
  • SEAT
    Syncros Belcarra Regular 2.5
  • HEADSET
    Syncros Pro Drop in / Tapered 1.5″-1 1/8″
    Bearing diameter size 42mm and 52mm
  • WHEELSET
    Front hub: Formula CL-811 / 12x110mm
    Rear hub: Formula CL-148S – Boost 12x148mmRims: Syncros X-25 / 32H / 25mm
    Tubeless ready
  • FRONT TIRE
    Maxxis Rekon / 2,4″ / Renforts Folding 60TPI
    Compatible Tubeless / EXO
  • REAR TIRE
    Maxxis Rekon / 2,4″ / Renforts Folding 60TPI
    Compatible Tubeless / EXO
  • APPROX WEIGHTS IN KG

    13.40

  • APPROX WEIGHTS IN LBS

    29.54

  • MAX. SYSTEM WEIGHT
    128 kg
    The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
